What is Rack Cabinet? Types of Rack Cabinets

Rack cabinets are the cabinets that provide the order and security of the devices used in systems such as network, satellite TV, announcement, data center. Rack cabinets are placed in system rooms and since they are standard in size, they are compatible with the devices to be placed inside. The mounting width is 19 inches as standard, the height dimension is expressed as "U" and 1U height is 44.45mm. As Tekniksat, we produce rack cabinets in heights between 4U and 47U. Rack cabinets are divided into two as wall type and free standing type according to their models.


For detailed information info@tekniksatcabinet.com



Free Standing Rack Cabinets





Free standing cabinets with wheels or with experienced wait ranging from 16U to 47U

These are the cabinets offered in 600X600, 600X800, 600X1000, 800X800, 800X1000mm dimensions. Supplied with glass front cover, mechanical lock, locked metal side panels and locked metal rear cover as standard. All panels and doors can be locked. It offers a variety of product options to meet all demands.


Wall Mount Rack Cabinets


Tekniksat wall mounting cabinets consist of two groups of models, soho and pro.




Wall Mounted Pro Rack Cabinets



The main difference between the 19 "Wall Mounted Pro Cabinets from SOHO models is that the side panels are locked and openable. Choose 600x600, 600x450 sizes, 7U to 20U height options. Easy access thanks to locked side panels. Full size smoked, high resistant to breakage, tempered, Antistatic 4.0 mm thick glass locked structure. The front door is made of tempered glass. 9035 gray, 9005 black, 2 colors to be selected.



Wall Mounted Soho Rack Cabinets






Wall mounted eco cabinets with physical dimensions of 19 "W: 520mm and D: 400mm have maximum usage depth in physical measurements and offer a wide range of users with 4 different heights from 4U to 12U.

Full size smoked, high resistant to breakage, tempered, antistatic, 4.0 mm thick glass and locked structure.

The front door is made of tempered glass. 9035 gray, 9005 black, 2 colors will be selected.
